Wholesale coffee bean packaging machine

Inquiry

Coffee bean packaging machine is suitable for coffee bean packaging and packing all kinds of 500-1000g Coffee Beans with stand up pouches, doypack with zipper, 3 side seal bags, 4 side seal bags, etc.

Coffee bean packaging machine is designed for the coffee farmer, coffee roasting house, roaster and coffee distributor who proceed with bulk production for wholesale, with good price!

Combination of coffee bean packaging machine production line:
The coffee bean produnction line mainly consists of an electronic scale, a working platform, a Z-type feeding machine, and coffee bean sealing machine.

Coffee bean packaging machine is specially developed for the packaging application of various composite film prefabricated bags, with compact structure and reasonable action, and machinery adopts point-touch color touch screen interface operation, the bag is placed on the top, and the position can be adjusted. It can operate a variety of bag types and sizes on a single machine, and the switching is easy and the workload is small.

Packing process of coffee bean packaging machine:
1. Bag storage socket: Place and store prefabricated pouch in bag socket, suitable for various bag types and sizes, easy to understand and easy to adjust.

2. Filling system by electronic weigher: The electronic weigher is the main working area of the machine, with a very compact structure, strong linear operation logic, and one-by-two movement, which make sure the filling is accurate.

3. Bag clamp: Machine woud automaticlly the grab the empty pouch. After the bag is taken out, the bag clamp clamps the side of the bag, and the position of the bag is fixed to facilitate the opening of the bag, filling, sealing and other actions until the finished product is released. The relative position of the two clamps can be adjusted to meet different bag sizes.

4. Bag opening, filling, inflation, pumping, material sorting, sealing, coding, and finished product output are concentrated.

5. Vacumm function: Machine would automatically proceed with the vacuum operation to extend product expiry, with steps of vacuuming with a vacuum pump:
1. Close the valves that communicate with the outside world, and open all valves that communicate with the system.
2. Unscrew the bypass hole screw plug of the exhaust valve, open the bypass hole, and connect the vacuum pump.
3. Start the vacuum pump to pump air.

Feature of Coffee bean packaging machine:
1. Wide range of pouches: All kinds of pre-made pouches such as flat and stand-up pouches (with/without zip)
2. Easy to operate: PLC and color panel, fault indication on the panel.
3. Easy to adjust: Only about 10 minutes to change different pouches.
4. Frequency control: Speed can be adjusted by frequency conversion within the range.
5. Water proof design: The machine surface can be washed down, so easy cleaning and longer useful life.
6. No pouch/incorrect pouch opening-no fill-no seal, machine alarm.
7. Machine alarm and stop when the inadequate air pressure.
8. Safety guards with safety-switches, machine alarm and stop when the safety guards are opened.
9. Hygienic construction, the product contact parts are adopted sus304 stainless steel.
10. Imported engineering plastic bearings, no need to oil, no contamination.
11. Oil-free vacuum pump, avoid the pollution of the production environmental.

Standard specification of Coffee bean packaging machine:

Type:	Coffee Bag Packing Machine Series
Product model:	H500Z
Product name:	Automatic coffee bag packing machine for coffee bean and coffee powder
Packing speed:	5-6 bags for vacuum packaging / minute; 10 - 45 bags for non vacuum packaging pouch per minutes
Filling range:	About 50-1000g like 250G, 500G, 1000G, 1KG coffee bean and powder in Vacuum Bag
Feature:	Vacuum packaging pouch
Bag size:	Length: 200-320mm; Width: 65-150mm = Premade bag or doypack bag.
Power:	220V, 50HZ, 2.5KW
Dimension (LWH):	140012001800mm
Weight:	650KG
