Hanging ear Drip coffee packaging machine is suitable for Drip coffee bag with outer envelope, available with ground coffee like Brazilian coffee, Guatemala coffee, Honduras coffee, Villa coffee and Arabica coffee, etc, and other small granule products.
Coffee power packing equipment adopts advanced PLC + servo motor + touch screen and other advanced modes. The whole set of equipment has stable performance, high precision, and all stainless steel structure. The entire filling process adopts an intelligent control system, which can complete the automatic positioning, filling and measurement of bag, etc, and It consists of a filling and measuring cup, a chain conveyor belt and a positioning device. It is an economical and practical automatic filling machine for powder and small particles.
In addition, this set of equipment is equipped with a well-positioned height adjustment handwheel, which is convenient for adjusting the height of the measuring cup to adjust the packing weight. Its supporting devices include: Measuring cup with hopper, Inner bag sealing system, outer bag sealer, online weighing and measuring device, and dust removal device if need.
2. Type of drip coffee bag: People from whole world used drip coffee bag between 90*74mm and 90*70mm because the drip coffee bag materials is a kind of standard products for packing machine.
3. The packaging materials for outer bag is Kraft paper bag or PE bag with aluminum foil, For more details, please kindly contact us.
4. Here shows how to brew the drip coffee bag with a cup and a bottle of hot water.
5. The main difference between heat sealing and ultrasonic sealed drip coffee bag is in Sealing Edge of Inner bag. For more details, please kindly contact us.
6. The standard packing for shipping we used is the Plywood Case with plastic film wrapping inside:
7. Nitrogen gas generator: Can supply the Nitrogen gas so that can be injected into drip coffee bag to extend coffee shelf life and keep coffee fresh. For more details, kindly contact for more details.
8. Here shows the working video of drip coffee bag packaging machine:
Except this video, welcome to click here to see more working video.
Standard Technical Data of hanging ear drip coffee packaging machine:
|
Type: |
Drip coffee packing machine Series |
|
Product model: |
H19D |
|
Product name: |
C19D Ultrasonic Drip Coffee Inner and Outer Bag Packing Machine |
|
Bag type: |
3 side sealing |
|
Outer Bag size: |
L:85~120mm,W:75~100mm (Film width 200mm, Bag size: 120*100mm) |
|
Inner Bag size: |
L:50~75mm, W:50~90mm (Filter paper width 180mm, Bag size: 90*75mm) |
|
Packing speed: |
40~60 bags/min |
|
Filling range: |
5~15g; accuracy:≦±0.1g/bag |
|
Measuring: |
Volumetric cup |
|
Inner Packing material |
Yamanaka Filter paper; Nylon filter mesh |
|
Outer packing material |
Kraft paper/aluminum coating; PE/aluminum coating; PE film |
|
Sealing method: |
Ultrasonic sealing and cutting for inner bag; Outer Bag by heat Sealing. |
|
Power: |
Single phase, 220V, 50HZ, 1.5KW |
|
Weight: |
600KG |
|
Dimension (L*W*H): |
1200*900*1900mm |
